DS-2CE76D3T-ITMF

2 MP Ultra Low Light Fixed Turret Camera

2 MP turret camera

Strong night performance, capturing images in ultra-low light down to 0.005 lux

Clear imaging even against strong back lighting due to 120 dB true WDR technology

3D DNR technology delivers clean and sharp images

EXIR 2.0: advanced infrared technology with 30 m IR distance

Water and dust resistant (IP67)

4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)

specification

Camera
Image Sensor2.0 megapixel progressive scan CMOS
Max. Resolution1920 (H) × 1080 (V)
Min. Illumination0.005 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & NightIR Cut Filter
Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
Signal SystemPAL/NTSC

Lens
Lens Type2.8 mm, 3.6 mm, 6 mm
Focal Length & FOV106° (2.8 mm), 82° (3.6 mm), 51° (6 mm)
Lens MountM12

Illuminator
Supplement Light TypeIR
Supplement Light RangeUp to 30 m
Smart Supplement LightYes

Image Parameters SwitchSTD/HIGH-SAT
Image SettingsBrightness;Mirror;Sharpness;AGC
Frame Rate
PAL: 1080p@25fps

NTSC: 1080p@30fps
Day/Night ModeAuto/Color/BW (Black and White)
Wide Dynamic Range (WDR)≥120 dB
Image EnhancementWDR;BLC;HLC
Noise Reduction3D DNR

Interface
Video Output1 HD analog output;Switchable TVI/AHD/CVI/CVBS

General
Power
12 VDC ±25%, max. 4.6 W

*You are recommended to use one power adapter to supply the power for one camera.
MaterialMetal
Dimension89.47 mm × 68.2 mm (3.52″ × 2.68″)
WeightApprox. 240 g (0.53 lb.)
Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
LanguageEnglish

Approval
ProtectionIP67
