DS-7716NXI-I4/S

16-ch 1.5U AcuSense 4K NVR

  • H.265+/H.265/H.264+/H.264 video formats
  • Intelligent analytics based on deep learning algorithm
  • Up to 4-ch perimeter protection
  • Up to 1-ch facial recognition for video stream, or up to 4-ch facial recognition for face picture
  • Up to 16-ch IP camera inputs
  • Up to 16-ch 1080p decoding capability
  • Up to 160 Mbps incoming bandwidth
  • specification

    • Facial Recognition
    • Facial Detection and AnalyticsFace picture comparison, human face capture, face picture search
    • Face Picture LibraryUp to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150 MB)
    • Face Picture Comparison4-ch face picture comparison alarm
    • Facial Detection and Analytics Performance1-ch human face capture (HD network camera, up to 4 MP, H.264/H.265)
    • Motion Detection 2.0
    • Human/Vehicle Analysis16-ch
    • Perimeter Protection
    • Human/Vehicle Analysis

      Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm;

      Up to 12 rules in total

    • Video and Audio
    • IP Video Input

      16-ch

      Up to 12 MP resolution

      *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.

    • Incoming Bandwidth160 Mbps
    • Outgoing Bandwidth256 Mbps
    • HDMI 1 Output4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA simultaneous output
    • HDMI 2 Output1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI2/VGA independent output
    • VGA Output

      1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,

      HDMI1/VGA simultaneous output

    • CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
    • Audio Output1-ch, RCA (Linear, 1 KΩ)
    • Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ)
    • Decoding
    • Decoding FormatH.265+/H.265/H.264+/H.264/MPEG4
    • Recording Resolution

      32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF

      *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.

    • Playback ModeNormal/Smart, Event, Tag, Eternal File
    • Synchronous Playback16-ch
    • Live View Window Division1/2/4/6/8/9/16
    • Aux Port Window Division1/2/4/6/8/9/16
    • Decoding Capability16-ch @ 1080p (30 fps)
    • Dual-Stream RecordingSupport
    • Stream TypeVideo, Video & Audio
    • Audio CompressionG.711ulaw/G.711alaw/G.722/G.726/MP2L2
    • Network
    • Remote Connection128
    • Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
    • Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
    • Auxiliary Interface
    • Serial InterfaceRS-485 (half-duplex), RS-232, Keyboard
    • SATA4 SATA interfaces supporting hot-plug
    • CapacityUp to 10 TB capacity for each disk
    • eSATA1 eSATA interface
    • Alarm In/Out16/4
    • USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
    • General
    • Power Supply100 to 240 VAC, 50 to 60 Hz
    • Consumption≤ 30 W (without HDD)
    • Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
    • Working Humidity10% to 90%
    • Chassis19-inch rack-mounted 1.5U chassis
    • Dimension (W × D × H)445 × 400 ×75 mm ( 17.5″× 15.7″ × 3.0″)
    • Weight≤ 5.6 kg (12.3 lb)
    • Certification
    • FCCPart 15 Subpart B, ANSI C63.4-2014
    • CEEN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
