DS-K1104

Pro 1104 Series Metal Vandal-proof Card Reader

Mifare 1 card reader

PC+zinc-alloy material shell

Built-in audible beeper

RS-485 and Wiegand interface

IK10

specification

System
Processor32-bit

Authentication
Card reading frequency13.56MHz
Card reading distance≤50mm (≤1.97″)

Function
ID settingsvia DIP Switch

General
IndicatorPower Indicator; Status LED Indicator
Power supply12V DC, ≤500mA
Power consumption≤2W
Working temperature-20°C to + 65°C (-4°F to + 149°F)
Working humidity10% to 90% (Non Condensing)
Protective levelIP65
Dimensions118 mm × 76 mm × 23 mm (4.65” × 2.99” × 0.91″)
InstallationApplied for 86 & 120 Gang Box
Weight≤ 0.52kg
ApprovalFCC, CE
KeypadNo Keypad (DS-K1104M)Keypad with 12 Keys (0 to 9, *, #) (DS-K1104MK)
Buzzersupported
