DS-K1108

Pro 1108 Series Card Reader

Mifare1/ EM card reader

Built-in audible beeper

Support RS-485, Wiegand (W26, W34), and OSDP protocol

IP65

specification

System
Processor32-bit

Interface
RS-485Support
WiegandSupport, set via DIP switch

Authentication
Card reading distance≤50mm (≤1.97″)

Function
ID settingsvia DIP Switch

General
IndicatorPower/Status
Power supplyDC 12V
Power consumption≤2W
Working temperature-20°C to +65°C (-4°F to +149°F)
Working humidity10% to 90% (Non Condensing)
Protective levelIP 65
Dimensions123mm × 88mm × 21mm (4.84″ × 3.46″ × 0.83″)
InstallationWall Mounting with/without Gang Box
ApprovalRadio Frequency Standard: ISO 14443-A
KeypadPhysical Key/No Key
BuzzerSupport
