DS-2CD1321-I

2 MP Fixed Bullet Network Camera

  • High quality imaging with 2 MP resolution
  • Efficient H.264 compression technology
  • Clear imaging against strong back light due to DWDR technology
  • Water and dust resistant (IP67)
  • EXIR 2.0: advanced infrared technology with long IR range
  • specification

    • Camera
    • Image Sensor1/2.7″ Progressive Scan CMOS
    • Max. Resolution1920 × 1080
    • Min. IlluminationColor: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
    • Shutter Time1/3 s to 1/100, 000 s
    • Day & NightIR cut filter
    • Angle AdjustmentPan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
    • Lens
    • Focal Length & FOV

      2.8 mm, horizontal FOV 105°, vertical FOV 58°, diagonal FOV 123°

      4 mm, horizontal FOV 81°, vertical FOV 43°, diagonal FOV 97°

    • Lens MountM12
    • Iris TypeFixed
    • ApertureF2.0
    • Illuminator
    • Supplement Light TypeIR
    • Supplement Light RangeUp to 30 m
    • Smart Supplement LightYes
    • IR Wavelength850 nm
    • Video
    • Main Stream

      50 Hz: 25 fps (1920 × 1080, 1280 × 720)

      60 Hz: 30 fps (1920 × 1080, 1280 × 720)

    • Sub-Stream

      50 Hz: 25 fps (640 × 480, 640 × 360)

      60 Hz: 30 fps (640 × 480, 640 × 360)

    • Video Compression

      Main Stream: H.264//H.264+

      Sub-Stream: H.264/MJPEG

    • Video Bit Rate32 Kbps to 8 Mbps
    • H.264 TypeBaseline Profile/Main Profile/High Profile
    • Region of Interest (ROI)1 fixed region for main stream
    • Network
    • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
    • Simultaneous Live ViewUp to 6 channels
    • APIOpen Network Video Interface, ISAPI
    • User/HostUp to 32 users. 3 levels: administrator, operator and user
    • ClientiVMS-4200, Hik-Connect
    • Web Browser

      Plug-in required live view: IE 10+

      Plug-in free live view: Chrome 57.0+, Firefox 52.0+

      Local service: Chrome 57.0+, Firefox 52.0+

    • Image
    • Image SettingsSaturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
    • Day/Night SwitchDay, Night, Auto, Schedule
    • Wide Dynamic Range (WDR)Digital WDR
    • SNR≥ 52 dB
    • Image EnhancementBLC, 3D DNR
    • Interface
    • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
    • Event
    • Basic Event Motion detection, video tampering alarm, exception
    • LinkageUpload to FTP, notify surveillance center, send email
    • General
    • Power

      12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug

      PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W

    • DimensionØ110 mm × 85.3 mm (Ø4.3″ × 3.4″)
    • Package Dimension150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
    • WeightApprox. 320 g (0.7 lb.)
    • With Package WeightApprox. 556 g (1.2 lb.)
    • Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
    • Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
    • LanguageEnglish, Ukrainian
    • General FunctionAnti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
    • Approval
    • EMCFCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
    • SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
    • EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
    • ProtectionIP67 (IEC 60529-2013)
