DS-2CE78K0T-LFS

3K Smart Hybrid Light Audio Fixed Turret Camera

High quality imaging with 3K, 2960 × 1665 resolution

2.8 mm and 3.6 mm fixed focal lens

Up to 40 m IR distance for bright night imaging

Up to 20 m white light distance for bright night imaging

One port for four switchable signals (TVI/AHD/CVI/CVBS）

Water and dust resistant (IP67)

specification

Camera
Image Sensor 3K CMOS
Max. Resolution2960 (H) × 1665 (V)
Min. Illumination0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter TimePAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s
Day & NightICR
Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°
Signal SystemPAL/NTSC

Lens
Lens Type2.8 mm and 3.6 mm fixed focal lens
Focal Length & FOV
2.8 mm, horizontal FOV: 104.9°, vertical FOV: 67.3°, diagonal FOV: 129.8°

3.6 mm, horizontal FOV: 81.3°, vertical FOV: 50.7°, diagonal FOV: 102.4°
Lens MountM12

Illuminator
Supplement Light TypeWhite Light;IR
Supplement Light Range
IR : Up to 40 m

White Light : Up to 20 m

Image SettingsBrightness, Sharpness, Smart IR
Frame Rate
TVI: 3K@20 fps, 4 MP@25 fps/30 fps, 1080p@25 fps/30 fps

AHD: 5 MP@20 fps, 4 MP@25 fps/30 fps

CVI: 4 MP@25 fps/30 fps

CVBS: PAL/NTSC
Day/Night ModeAuto/Color/BW (Black and White)
Wide Dynamic Range (WDR)Digital WDR
Image EnhancementDWDR/BLC/HLC/Global
White BalanceAuto/Manual
AGCYes

Interface
Video OutputSwitchable TVI/AHD/CVI/CVBS

General
Material
Body：Metal

Enclosure： Plastic
Dimension97.9 mm × Ø110 mm (3.85″ × Ø4.33″)
WeightApprox. 340 g (0.75 lb.)
Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
CommunicationHIKVISION-C
LanguageEnglish
Power Supply
12 VDC ± 25%

*You are recommended to use one power adapter to supply the power for one camera.
ConsumptionMax. 3.3 W

Approval
ProtectionIP67
