DS-7708NI-K4/8P

8-ch 1.5U 8 PoE 4K NVR

Up to 8 channel IP cameras can be connected

Supports decoding H.265+/H.265/H.264+/H.264 video formats

Up to 8-ch @ 1080p decoding capacity

1 HDMI and 1 VGA interfaces: both interfaces support independent video output

4 HDDs for continuous video recording

Plug & Play with 8 Power-over-Ethernet (PoE) interfaces

Supports various specific function cameras, including thermal camera /fisheye/people counting/heatmap/ANPR (automatic number plate recognition)

Channel-zero function ensures smooth remote live view and playback in low bandwidth environments

specification

Video and Audio
IP Video Input8-ch ;8-ch
HDMI Output4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz;HDMI,VGA
Incoming Bandwidth80 Mbps 160 Mbps
Audio Output1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio1-ch, RCA (2.0 Vp-p, 1kΩ)

Decoding
Decoding FormatH.265/ H.265+/H.264/H.264+/MPEG4;H.265+,H.265,H.264+,H.264
Decoding Capability2-ch @ 8 MP (25fps) / 4-ch @ 4MP (30fps) / 8-ch @ 1080p (30fps);8-ch@1080p
Synchronous playback8-ch
Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF /2CIF/CIF/QCIF

Network
Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Interface1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

PoE
Interface8-ch;8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power≤ 200 W
StandardIEEE 802.3 af/at

RAID
RAID TypeNo

Auxiliary Interface
SATA4 SATA interfaces ;4
CapacityUp to 6 TB capacity for each HDD
Serial Interface1 RS-485 (half-duplex), 1 RS-232, 1 keyboard (optional)
USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm In/Out16/4

General
Power Supply100 to 240 VAC;≤ 300 W
Consumption≤ 20 W (without enabling PoE)
Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity10 to 90 %
Dimension (W × D × H)445 × 400 ×71 mm ( 17.5″× 15.7″ × 2.8″)
Weight≤ 5 kg (11. lb)
