DS-7708NI-Q4

8-ch 1.5U 4K NVR

Up to 8-ch IP camera inputs

H.265+/H.265/H.264+/H.264 video formats

Up to 1-ch @ 8MP or 2-ch @ 4MP or 6-ch @ 1080P decoding capacity

1 HDMI and 1 VGA interfaces: simultaneous video output

Up to 80 Mbps incoming bandwidth

4 HDDs for continuous video recording

specification

Video and Audio
IP Video Input8-ch
HDMI Output1-ch, 4K (3840 × 2160)/30Hz, ,1920 × 1080p/60Hz, ,1600 × 1200/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
VGA Output1-ch, 1920 × 1080/60Hz, ,1280 × 1024/60Hz, ,1280 × 720/60Hz, ,1024 × 768/60Hz; ,
Incoming Bandwidth80 Mbps
Audio Output1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)

Decoding
Decoding FormatH.265/H.265+/H.264/H.264+/MPEG4
Decoding Capability1-ch @ 8 MP (30 fps) / 4-ch @ 1080p (30 fps)
Synchronous playback8-ch
Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF

Network
Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

PoE
InterfaceN/A

RAID
RAID TypeNo

Auxiliary Interface
SATA4
CapacityUp to 6 TB capacity for each disk
Serial Interface1 RS-485 (half-duplex), 1 RS-232
USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 2.0
Alarm In/Out16/4 (16/8 optional)

General
Power Supply100 to 240 VAC,≤ 80 W
Consumption≤ 15 W
Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity10 % to 90 %
Dimension (W × D × H)440 × 393 × 75 mm (17.3″ × 15.5″ × 3.0″)
Weight≤ 5 kg (11 lb)
