DS-2CD6425G2-C2

L10 model:

3.7 mm, horizontal FOV 77.5°, vertical FOV 39.4°, diagonal FOV 94.1°

L20 model:

2.8 mm, horizontal FOV 93.8°, vertical FOV 51.7°, diagonal FOV 109.3°

3.7mm, horizontal FOV 77.5°, vertical FOV 39.4°, diagonal FOV 94.1°

L30 model:

2.8 mm, horizontal FOV 109.0°, vertical FOV 60.0°, diagonal FOV 128.3°

4 mm, horizontal FOV 82.8°, vertical FOV 45.1°, diagonal FOV 98°

L10/L20:

2.8 mm: D: 47.9 m, O: 19 m, R: 9.6 m, I: 4.8 m

3.7 mm: D: 59.3 m, O: 23.5 m, R: 11.9 m, I: 5.9 m

L30:

2.8 mm: D: 41 m, O: 16 m, R: 8 m, I: 4 m

4 mm: D: 55.2 m, O: 21.9 m, R: 11 m, I: 5.5 m

Memory: 60 MB,

Smart RAM: 375 MB,

eMMC: 2 GB

50 Hz: 50 fps (1920 × 1080, 1280 × 960, 1280 × 720)

60 Hz: 60 fps (1920 × 1080, 1280 × 960, 1280 × 720)

50 Hz: 25 fps (704 × 576, 640 × 480)

60 Hz: 30 fps (704 × 480, 640 × 480)

50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480)

60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480)

Main stream: H.265/H.264,

Sub-stream: H.265/H.264/MJPEG,

Third stream: H.265/H.264

Up to 32 users

3 user levels: administrator, operator, and user

Plug-in required live view: IE11,

Plug-in free live view: Safari 12+,

Local service: Chrome 57.0+, Firefox 52.0+

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB

12 VDC ± 20%, 0.53 A, max. 6.4 W,

PoE: IEEE 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.13 A, max. 7.4 W

Kit/Main body: 219 mm × 139 mm × 60 mm (8.6 × 5.5″ × 2.4″)”

Main body: approx. 180 g (0.39 lb.)

Package: approx. 383 g (0.84 lb.)

FCC: 47 CFR Part 15, Subpart B,

CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,

RCM: AS/NZS CISPR 32: 2015,

IC: ICES-003: Issue 7,

KC: KN32: 2015, KN35: 2015

CB: IEC 62368-1: 2014+A11,

CE-LVD: EN 62368-1: 2014/A11: 2017,

BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,

LOA: IEC/EN 60950-1

CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006
