DS-2CE70DF3T-PTS

2MP ColorVu Indoor Audio Fixed PT Camera

  • High quality imaging with 2 MP, 1920 × 1080 resolution
  • 24/7 color imaging with F1.0 aperture
  • Clear imaging against strong back light due to 130 dB true WDR technology
  • 3D DNR technology delivers clean and sharp images
  • Fixed focal lens, 2.8, and 3.6 mm optional
  • Up to 20 m white light distance for bright night images
  • High quality audio with audio over coaxial cable, built-in microphone
  • specification

    • Camera
    • Image Sensor2 MP CMOS
    • Max. Resolution1920 (H) × 1080 (V)
    • Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
    • Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
    • Day & Night24/7 Color Imaging
    • Angle Adjustment

      Pan: 0 to 350°, tilt: 0 to 75°

      *DO NOT adjust the angle of the main body or enclosure manually.

    • Signal SystemPAL/NTSC
    • Slow ShutterMax. 16 times
    • Lens
    • Lens TypeFixed focal lens, 2.8 and 3.6 mm optional
    • Focal Length & FOV

      2.8 mm, horizontal FOV: 106°, vertical FOV: 57°, diagonal FOV: 126°

      3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 99°

    • Lens MountM12
    • Illuminator
    • Supplement Light TypeWhite Light
    • Supplement Light RangeUp to 20 m
    • Smart Supplement LightYes
    • Image
    • Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
    • Image SettingsBrightness;Contrast;Mirror;Sharpness;Anti-Banding;Saturation;AGC
    • Frame RateTVI: 1080P@25 fps/30 fps
    • Day/Night ModeColor
    • Wide Dynamic Range (WDR)≥130 dB
    • Image EnhancementBLC;HLC;Global;HLS
    • Privacy Mask4 programmable privacy masks
    • Noise Reduction3D DNR/2D DNR
    • White BalanceAuto/Manual
    • White LightAuto/Off
    • Interface
    • Video Output1 HD analog output
    • AlarmSolid Light Alarm (White Light)
    • Built-in MicrophoneYes
    • Event
    • Motion Detection4 programmable motion areas
    • General
    • Power

      12 VDC ± 25%, max. 7.4 W

      *You are recommended to use one power adapter to supply the power for one camera.

    • MaterialPlastic
    • DimensionØ123.7 × 110.8 (4.9″ × 4.4″)
    • WeightApprox. 290 g (0.6 lb.)
    • Operating Condition-10 °C to 40 °C (14 °F to 104 °F). Humidity 90% or less (non-condensing)
    • CommunicationHIKVISION-C
    • LanguageEnglish
